Equipment & Services Request Process:
- Bellow you will find the “Equipment” table – a detailed list of equipment available for use by Center member Principal Investigators (PIs).
Each piece of equipment has its usage cost listed. - Click on the “Submit” button next to the equipment you wish to rent and you will be forwarded to the “Equipment rental form”.
- Fill in the Details:
Complete the form by providing the required information. - Confirmation and Scheduling: Upon submission, your request will be reviewed by the Center’s administrative staff. You will receive a confirmation email with further instructions and a schedule for the use of the requested equipment.
Center’s Equipment
| Research Infrastructure (RI) | Specifications | Usage Fee | Location | Principal Investigator | Technologies | Image | |
|---|---|---|---|---|---|---|---|
| Spectrometer + ICCD |
o Wavelength range: 300 – 800 nm o Andor iStar ICCD o Gate time: 4 ns |
Aerospace Engineering, Technion | Prof. Lefkowitz | Submit | |||
| Laser-induced fluorescence |
o Nd:YAG + dye laser o Wavelength range: 200 – 600 nm o Rep rate: 20 Hz o Pulse duration: 6-10 ns |
Aerospace Engineering, Technion | Prof. Lefkowitz | Submit | |||
| High-speed imaging |
o Four mid-IR units (4 – 6 μm) o H2O, CO2, NO, CH2O detections o < 50 mW power o < 10,000 Hz scan rate |
Aerospace Engineering, Technion | Prof. Lefkowitz | Submit | |||
| Tunable diode lasers/detectors |
o Four mid-IR units (4 – 6 μm) o H2O, CO2, NO, CH2O detections o < 50 mW power o < 10,000 Hz scan rate |
Aerospace Enginreeing, Technion | Prof. Lefkowitz | Submit | |||
| Hyperspectral Infrared Imaging |
(currently being upgraded) o Telops Hyper-Cam MWE FAST o Spectral range: 1.5 – 5.4 μm o Spectral resolution: 0.25 – 150 cm-1 o Spatial resolution: 320 x 256 pixels o Frame rate: 0.032 – 32 cubes/s o Exposure time: 1 μs – full frame |
Aerospace Engineering, Technion | Prof. Lefkowitz | Submit | |||
| High-speed IR imaging |
o Telops FAST M3k o Spectral range: 1.5 – 5.4 μm o Resolution: 320 x 256 pixels o Frame rate: 3,100 fps (full res) – 100,000 fps (64 x 4 pixels) o Exposure time: 1 μs – full frame |
Aerospace Engineering, Technion | Prof. Lefkowitz | Submit | |||
| GC-MS |
o Thermo Scientific Trace 1300 GC o PIONA Analysis o H2 – C15 capability o Gas or liquid injection |
Aerospace Engineering, Technion | Prof. Lefkowitz | Submit | |||
| High Brightness, Laser-Driven Light Source | price will be presented after the purchase and pricing at BGU | Department of Chemistry, Ben-Gurion University | Prof. Baraban | Submit | |||
| HPC Node | pricing after the purchase and pricing of BILAN | Chemistry faculty, Bar Ilan | Prof. Major | Submit | |||
| LCA | according to project | Civil & Environmental engineering, Technion | Prof. Spatari | Submit | |||
| Predictive chemical kinetic model development | according to project | Chemical engineering, Technion | Prof. Grinberg Dana | Submit | |||
| Model refinement using quantum chemical computations | Chemical engineering, Tecnion | Prof. Grinberg Dana | Submit | ||||
| Chemical kinetic Model generation using the Reaction Mechanism Generator software | Chemical engineering, Technion | Prof. Grinberg Dana | Submit | ||||
| Lab scale continuous (membrane) reactor system | for high temperature and pressure reactions (up to 500 C, 40 bar) with on line MS | Chemical Engineering, Technion | Prof. Shoham Patrascu | Submit | |||
| FTIR | high temperature reaction cell, capable of rapid scan | Chemical Engineering, Technion | Prof. Shoham Patrascu | Submit | |||
| GC-MS | capable of analyzing jet fuel composition (and lighter fuel fractions) | Chemical Engineering, Technion | Prof. Shoham Patrascu | Submit | |||
| Thermal treatments at high temperatures and various gas atmospheres | Chemical engineering, Technion | Prof. Grader | Submit | ||||
| Surface area measurements of powders using the BET method | Chemical engineering faculty, Technion | Prof. Grader | Submit | ||||
| TA Instruments SDT 650 | Simultaneous DSC (differential scanning calorimetry) and TGA (thermogravimetric analysis) data collection | Aerospace Engineering Faculty, Technion |
Prof. Shoham Patrascu |
Submit | |||
| Computer servers | Faculty of Materials Engineering, Technion | Prof. Caspary Toroker | Submit | ||||
| Combustion test facility for SAF testing | Aerospace Engineering Faculty, Technion | Prof. Cukurel | Submit | ||||
| Room temperature GPC | Faculty of Chemistry, Technion | Prof. Eisen | Submit | ||||
| GC with TCD and FID detectors | Faculty of Chemistry, Technion | Prof. Eisen | Submit | ||||
| High-pressure/high-temperature reactor | Faculty of Chemistry, Technion | Prof. Eisen | Submit | ||||
| small-size reactors | Faculty of Chemistry, Technion | Prof. Eisen | Submit | ||||
| UYA 2.4Y.F Ultra-Microbalance |
ultra-microbalance is an optimized modern device which features an option of automatic level control (Level SENSING) as one of numerous functions. The practical effect of balance customization are individual user profiles and gradable permission levels for access to balance menu. Programmable proximity sensors offer wide range of possibilities: weighing chamber control, zeroing, tarring, printout. Several functions such as differential weighing facilitate multistage mass control of one and the same sample subjected to various processes. Pipettes calibration function is an ergonomic tool designed to calibrate and control piston pipettes with the use of gravimetric method. MEDIA module, as one of the greatest 4Y series assets, provides the user with an on-screen help and support. |
240 NIS per hour (excluding 18% VAT) | Rooms 304, 316, Faculty of Chemical Engineering, Technion |
Prof. Dekel |
Submit | ||
| potentiometric titrator (751 GPD Titrino, Metrohm) |
This instrument can determine the concentration of a given analyte, which helps to determine the amount of ion exchange group of membrane samples. |
240 NIS per hour (excluding 18% VAT) |
Rooms 304, 316, Faculty of Chemical Engineering, Technion |
Prof. Dekel |
Submit | ||
| membrane testing system (MTS 740, Scribner Associates Inc.) |
• Wet and dry gas mixing for accurate and precise RH control and rapid RH cycling • Test chamber backpressure control, condenser and collection tank for high - temperature operation • In -situ sample temperature and dew point measurement for real -time RH monitoring • Uses bare (non -catalyzed) membranes • Small sample size 6 mm x 30 mm • Spring -loaded sample compression—easy, repeatable sample loading up to 400 PSI (2.76 MPa) • Control and monitoring of multiple process temperatures • Rapid, easy cell assembly with accurate and repeatable sample compression • Cell lock -feature for safe operation at elevated temperature, pressure and H2 gas • Automatic shutdown and N2 purge on alarm condition • Detailed cell assembly instructions and data analysis procedure • Native USB interface to PC for easy set -up • Safety features include alarm conditions and automatic hardware shutdown for safe, reliable operation. |
240 NIS per hour (excluding 18% VAT) | Rooms 304, 316, Faculty of Chemical Engineering, Technion |
Prof. Dekel |
Submit | ||
| Bench Top Manual Presses |
Designed for an array of different applications and processes for example; pelletizing, destructive testing, rosin and other fluid extraction, pressure forming, etc. |
240 NIS per hour (excluding 18% VAT) | Rooms 304, 316, Faculty of Chemical Engineering, Technion | Prof. Dekel | Submit | ||
| Greenlight G20 fuel cell testing station |
• Available with Greenlight's integrated 'Intelligent Fuel Cell Diagnostics' capabilities: FCDX™ • G20 power range: up to 100 Watts • Manual and automated operation • Emerald control software • Automated scripting capability • Safety systems for unattended operation • Computer and monitor included • Cost effective bench-top design • Optional configuration for high temperature PEM research • Optional fuel cell hardware available • Optional diagnostics, including AC impedance and cyclic / linear sweep voltammetry Available CE certificate of conformity |
240 NIS per hour (excluding 18% VAT) | Rooms 304, 316, Faculty of Chemical Engineering, Technion |
Prof. Dekel |
Submit | ||
| Y&D7300N bench -top robot |
This product has a wide range of applications, such as watch, relay packaging, mobile phone key dispensing, mobile phone battery packaging, notebook battery packaging, coil dispensing, PCB binding sealing, IC sealing, horn outer ring dispensing, PDA sealing, LCD sealing and so on. |
240 NIS per hour (excluding 18% VAT) |
Rooms 304, 316, Faculty of Chemical Engineering, Technion |
Prof. Dekel |
Submit | ||
| Raman spectroscopy |
Raman spectroscopy relies upon inelastic scattering of photons, known as Raman scattering. The Raman peaks are interpreted as individual chemical moieties, thus providing an insight into the chemistry of a reaction and the extent of reaction progress. Monochromatic light, usually from a laser in the visible range is used as a source for photons. Kaiser RXN1 raman spectrometer has laser wavelength of 785 nm. |
240 NIS per hour (excluding 18% VAT) |
Rooms 304, 316, Faculty of Chemical Engineering, Technion | Prof. Dekel | Submit | ||
| 875 Redox Flow Cell Test System |
• 0.07 A, .07 A, 7 A, 20 A current range • High-current, multi-range potentiostat operates in current - or voltage -controlled operation • ± 5 V operation for non -aqueous electrolytes • Charge / discharge cycling & performance characterization • Four reservoir sizes - 100 mL, 250 mL, 500 mL, and 1 L • Whole and half-cell voltage, EIS and HFR measurement • Impedance Analyzer for EIS and HFR measurements during charge, discharge and at OCV • High -impedance V -sense inputs for whole and half-cell measurements including EIS & HFR • State -of-charge (SOC) voltage inputs for DC SOC measurement when used with SOC cell • All non -metallic electrolyte handling system: pumps, electrolyte reservoirs, drain and purge valves • Cell and electrolyte temperature control up to 50 oC • Peristaltic pumps with variable flow control including forward and reverse • Electrolyte shielding with inert gas purge blanket • Electrolyte reservoir stirring |
240 NIS per hour (excluding 18% VAT) | Rooms 304, 316, Faculty of Chemical Engineering, Technion | Prof. Dekel | Submit | ||
| Glovebox |
The intelligent system of the Internet of Things can be installed to realize the motion control and centralized management of the glove box, which is safe and secure. It has intelligent functions such as real -time synchronization of equipment status, equipment data report records, historical data query, active notification of alarm messages, remote commissioning, online fault diagnosis and online repair, online customer service and other intelligent functions. Control system: Siemens PLC Purifier: single column Moisture content: <1ppm Oxygen level :<1ppm |
240 NIS per hour (excluding 18% VAT) | Rooms 304, 316, Faculty of Chemical Engineering, Technion | Prof. Dekel | Submit | ||
| Eppendorf® Centrifuge 5804 |
• Max. capacity: 4 × 250 mL/2 × 5 MTP • Swing-bucket rotors and adapters accommodate tubes and bottles from 0.2 mL to 250 mL • Plate rotor for centrifugation of all types of MTP, PCR, cell culture, or Deepwell Plates • Fixed-angle rotors for high-speed applications in tubes from 0.2 mL to 85 mL • High centrifugation speed of up to 20,913 × g (14,000 rpm) • Centrifuge lid with soft-touch lid closure • Low access height of 29 cm for easy loading and unloading of samples • Quiet operation to improve your work environment • Compact footprint saves valuable bench space Automatic rotor recognition and imbalance detection for maximum operational safety |
240 NIS per hour |
Rooms 304, 316, Faculty of Chemical Engineering, Technion |
Prof. Dekel | Submit | ||
| WaveDriver 40 DC Bipotentiostat |
This WaveDriver® series bipotentiostat/galvanostat is an affordable dual-electrode electrochemical workstation. The WaveDriver 40 is a true integrated bipotentiostat, capable of controlling one or two working electrodes operating in the same electrochemical cell along with a counter and reference electrode, making this instrument ideal for Rotating Ring-Disk Electrode (RRDE) voltammetry. Applied/Measured Current Ranges: ±100 nA to ±1 A; applied/Measured Potential Ranges: ±2.5 V, ±10 V, ±15 V. DC Techniques: All popular potentiostatic and galvanostatic sweep and step methods are included (BE, CV, LSV, CA, DPV, SWV, NPV, ASV, OCP, ZRA, RCP, etc.) |
240 NIS per hour | Chemical Engineering, Technion | Prof. Dekel | Submit |
